Drive Axle Forklift

Forklift Drive Axle - The piece of equipment that is elastically connected to the frame of the vehicle using a lift mast is known as the lift truck drive axle. The lift mast connects to the drive axle and could be inclined, by at least one tilting cylinder, around the axial centerline of the drive axle. Forward bearing elements along with rear bearing components of a torque bearing system are responsible for fastening the drive axle to the vehicle frame. The drive axle could be pivoted round a swiveling axis oriented horizontally and transversely in the vicinity of the rear bearing elements. The lift mast is likewise capable of being inclined relative to the drive axle. The tilting cylinder is attached to the lift truck frame and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented almost parallel to a plane extending from the swiveling axis to the axial centerline.

Unit H45, H35 and H40 forklifts, that are made by Linde AG in Aschaffenburg, Germany, have a connected lift mast tilt on the vehicle framework itself. The drive axle is elastically connected to the frame of the forklift using numerous different bearings. The drive axle has tubular axle body together with extension arms affixed to it and extend backwards. This kind of drive axle is elastically attached to the vehicle framework by back bearing elements on the extension arms along with forward bearing devices located on the axle body. There are two rear and two front bearing tools. Each one is separated in the transverse direction of the lift truck from the other bearing device in its respective pair.

The braking and drive torques of the drive axle are sustained through the rear bearing elements on the frame utilizing the extension arms. The lift mast and the load produce the forces which are transmitted into the roadway or floor by the frame of the vehicle through the drive axle's anterior bearing elements. It is vital to make sure the parts of the drive axle are constructed in a firm enough manner in order to maintain stability of the forklift truck. The bearing parts could reduce minor bumps or road surface irregularities all through travel to a limited extent and provide a bit smoother operation.
